Характеристики
ANDDEAR-G-8 is a 10/100/1000M Fast Ethernet switch 4/8port 4/8 pin header port. All ports support Auto MDI / MDIX function and each port can be used as general ports or Uplink port, is a simple configuration, plug and play of Ethernet switches. Exquisite form factor is a specifically designed for the home network cabling, and can provide for multiple home computers to share information, is cost-effective network product, Exquisite form factor is is widely used home,hotel,commercial and other multimedia cabling box, and the network data Transmission, cabling distance extend and other.
Features
Complies with IEEE802.3, IEEE802.3u standards
4/8 10/100/1000Mbps Auto-Negotiation
Each ports supporting Auto-MDI/MDIX.
Supports storage-forward
Supports Full Duplex flow control mode and backpressure for half-duplex mode.
Supports MAC address auto-learning and auto-aging.
Each port provides independent bandwidth providing true non-blocking transmission
LED indicators for monitoring power, link, activity.
Small size to reduce network cabling costs
Application
Exquisite form factor is widely used home,hotel,commercial and other multimedia cabling box, and the network data Transmission, cabling distance extend and other.
Specification
|
Standards |
IEEE802.3 10Base-T, IEEE802.3u 100Base-TX |
|
Ports |
4/8 10/100/1000Mbps Auto-Negotiation ports |
|
Network Media(Cable) |
10Base-T: UTP category 3, 4, 5 cable (maximum 100M), EIA/TIA-568 100Ù STP (maximum 100M), 100Base-Tx: UTP category 5, 5e cable (maximum 100M), EIA/TIA-568 100Ù STP (maximum 100M) |
|
Switching capacity |
8G |
|
LED Indicators |
1000Mbps Link/Act Power |
|
Transfer Method |
Store-and-Forward |
|
MAC Address Learning |
Automatically learning, automatically Update |
|
Frame Filtering and Forward Rate |
10Mbps: 14880pps, 100Mbps: 148800pps |
|
Dimension |
65*54*1.6mm |
|
Environment |
Operating Temperature: 0°C~40°C (32°F~104°F), Storage Temperature: -40°C~70°C(-40°F~158°F), Operating Humidity: 10%~90% non-condensing, Storage humidity: 5%~90% non-condensing |
|
Power |
External, 5V~ 1A,12V~1 |
