DC 0-100V 1A Digital Voltmeter Ammeter Dual Display Voltage Detector Current Meter Panel Amp Volt Gauge 0.28 Inch Red LED | Электроника

Характеристики

DC 0-100V 1A Digital Voltmeter Ammeter Dual Display Voltage Detector Current Meter Panel Amp Volt Gauge 0.28 Inch Red LED DIY Supplies: Electrical
Display Type: Digital Only
Accuracy Class: 1%
Operating Temperature: 10 to 80% (non-condensing)
Model Number: Digital Voltmeter Ammeter
Power Supply: DC
Minimum resolution (A): 0.01A
Measure current: 1A~10A (direct measurement, built-in shunt).
Measure voltage: DC 0 ~ 100V
Operating voltage: Operating voltage: DC 4.5 ~ 30V
Minimum resolution (V): 0.1V
100% Brand new and high quality!
Combines two functions in one
Current (A), Voltage (V)
It is miniature, accuracy, and more cost-effective.
One digital meter can use as two, and save space and bring more economy for user.
Working current of Meter itself:less than or equal to 20mA
Voltage Measuring range: DC 0 - 100V
Current Measuring range: DC 0 - 10A
Voltage resolution (V): +/-0.1%
Current resolution (A): +/-1%
Display: 0.28 inch digital tube, Two color blue and red
Operation Temp: -10 Celsius-+65 Celsius
Refresh rate: about 300mS / times
colour:black
material:ABS
size:49*29*22mm
Display: 0.28 Inch
Package Contents:
1x DC 100V 10A Voltmeter & Ammeter
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
