CT26 11 + 0 лопастей 48 30/64 89 мм турбо алюминиевый 2618/Фрезерование/заготовка колеса

Характеристики

1.  MODEL:GT15-25 FORWARD

2.GT15-25 50.00/68.01mm 7+7 blades high performance point milling air curve turbo milling/aluminum 2618/billet compressor wheel

3.Size:

Nose diameter:11.80mm

inducer:50.00mm

Exduder:68.01mm

Tapered tip exducer:73.16mm

Tip height:5.46mm

Superback:3.71mm

Overall height:34.00mm

  bore size :5.08mm

Trailing Angle:45

Cutback:0.0

Blades height:28.20mm

sp Height Angle:-7.70

Splitter height:17.00mm

7+7 blades

forward rotation

Tapered tip Angle:30 degree

 It is custom size ,please check carefully before buying.

 4.High quality and competitive price.

5.if you want more details, please send email to me.

We can produce as your requirement.

The more models we also have.
