Electronic Throttle Control Motor 993647060 / 73541900 For German Car American Automotive |

Характеристики

Throttle Motor
ORIGINAL OE Electronic Throttle Control MOTOR 993647060 / 73541900
FOR GERMAN CAR AMERICAN CAR'S TURBO CHARGE
OEM No.: 993 647 060/ 73541900
Color: silver
material: metal
PMDC Motor
Robust, low cost and long life
standard motor for idle speed control
Application:
Electronic Throttle Control
Motor Characteristics:
Diameter : 27.9 mm
Length : 46.5 mm
Shaft Diameter : 2.305 mm
Nominal Voltage : 12.0 V
Torque Constant : 16.003 m-Nm/A
Dynamic Resistance : 3.990 Ohms
Motor Regulations : 153.225 Rpm/m-Nm
Electrical Performance:
No Load Stall Max Eff Max Power
Speed (Rpm) 6900 5600 3500
Current (A) 0.180 3.008 0.736 1.594
Torque (mNm) 45.25 8.89 22.63
Efficiency (%) 58.79
Power (W) 5.190 8.217
Robust, low cost and long life
standard motor for idle speed control
Package Contents: 1* car throttle motor
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
