Характеристики
Description:
Easy installation & no driver required.
No additional power required.
Support boot function.
Supports any OS, like Windows, WinCE & Linux etc.
Specification:
Connects NGFF B Key SSD to mSATA Mini PCI-E motherboard.
Compliant with PCI Express M.2 specification 1.0.
Compliant with SATA III specification.
Supports data transfer up to 6.0Gb/s.
Supports SATA-based NGFF SSD.
Supports B Key NGFF SSD.
Supports 2230, 2242, 2260 & 2280 size NGFF SSD.
One NGFF M.2 B Key socket and one mSATA Mini PCI-E male connector available.
4 screw holes 2230/2242/2260/2280 available to fix NGFF SSD card.
4 screw holes available to fix PCB board.
Board Size:(L*W)9.90*6.60cm/3.89"*2.60"
Package Includes:
1pc*NGFF M.2 B Key to mSATA Adapter Card
Note:
1. Due to the light and screen difference, the item's color may be slightly different from the pictures.
2. Please allow 1-2 cm differences due to manual measurement.
