Maytech (8pcs) Free shipping e-skateboard longboard elettrico combo 5065 motor
(MTSKT1613B+MTSKM1617+MTSKP1612-2+MTVESC50A+MTSKR1712+MTO5065-170-HA-C +2xMTSKW8352B)

Four options:
Bundle1: 1xback truck+1xmount+1xmotor+1xpulleys&belt+1xVESC+1xremote+2xwheels Blue
Bundle2: 1xback truck+1xmount+1xmotor+1xpulleys&belt+1xVESC+1xremote+2xwheels Green
Bundle3: 1xback truck+1xmount+1xmotor+1xpulleys&belt+1xVESC+1xremote+2xwheels Red
Bundle4: 1xback truck+1xmount+1xmotor+1xpulleys&belt+1xVESC+1xremote+2xwheels White

1. Maytech electric longboard kit 5065 170KV brushless outrunner motor with hall sensor (1pcs)

KV	170
Size	50X65
Shaft	8mm
Max Current	50A
Max Power	1815W
Weight	750g
Max Lipo Cell	2-10 lipos
With	Hall sensor

Waterproof & Dustproof IP (INGRESS PROTECTION): IP54

Notice:

1.   Mount your motor with the included screws tightly on your front cover of model.

2.   Our motors provide high efficiency stator design.

3.   Small size, lightweight and long life.

4.   Maytech motors are designed for running clockwise or counterclockwise. To change the turning direction, you just simply exchange 2 of the 3 cables.

2. Maytech electric skateboard truck (1pcs)

Model No	MTSKT1613B
Material	Aluminium
Size	7inch / 180mm
Weight	800
Type	equipped with double conic bushing

3. Maytech electric skateboard motor mount (1pcs)

Model No	MTSKM1617
Material	Aluminium alloy
Suitable for	50/63mm motors (with mounting holes like following picture)
Weight	165g
Suitable truck	Maytech back truck MTKT1613B

4. Maytech electric skateboard electric motor pulley wheel pulley with belt (1set)

Model No	MTSKP1612
Nylon wheel pulley	1x17mm wide
Steel motor pulley	1x17mm wide
Belt	1x15mm wide
Weight	800g

1. Wheel Pulley:
17mm width
Bore diameter of the bearing is 8mm;
Teeth amount is 60.

2. Motor Pulley:
17mm width
Bore diameter is 8mm;
Teeth amount is 20.

3. Belt HTD-255 3mm
255mm long
85teeth
Distance between 2 adjacent teeth is 3mm.

5. Maytech electric skateboard PU wheels (2pcs)

Model No	MTSKW1614R with bearings
Material	85% rebound PU wheels
Size	83x52mm
Weight	500
Color	Red or Blue

85% rebound PU wheels ensure the best trafficability and shock absorption.

6. Maytech electric skateboard longboard remote control with receiver (1pcs)

Model NO	MTSKR1712
Power	Battery
Battery	3.7V 420mAH
Application	for electric Skateboard
Working current	26mA
Certificate	CE ROHS
Materials	Plastic
Color	Black
Feature	small & light
Material	Plastic case

Test video: //youtu.be/cfakbqefvLM

Advantages:

Smaller size; Easy to pair; Two speed levels; More economic;

Functions:
1. 2.4GHZ two-way communication, 126 channel, automatic frequency modulation for anti-interference;
2. 40bit ID code, very low probability of repeated code;
3. 20 meters communication distance; 16 hours working time after fully charged;
4. Built-in 420Mah lithium battery, with USB Charger Port
5. With Blue/Green LED lights, remote case is strong, and resist cracks.;
6. High and low speed can be easily switched.
7. Automatic throttle calibration when power on;
8. Reminder when remote control and receiver lose communication; when signal losses for 5 minutes,
remote will automatically shut down to save power;
9. When the remote control and receiver lose communication, receiver will turn off the throttle to protect
the rider;
10. Match-code memory function, remote control and receiver has fast connection when power on.
11. LED will flash red when remote battery voltage is low;
12. Forward and Reverse switching function *
13. LED indicates Skateboard battery *
Note: Functions with * need to be used with dual ESC MTDU30A.



7. Maytech electric skateboard longboard 50A 12S VESC (1pcs)

Application	e-skateboard
BEC	5V BEC
Lipo	3-12Cells
Voltage	8V-60V
Hardware version	4.12
Firmware version	2.18
Capacitors	3pcs 680uf 63V
Dimension of VESC board	60x40mm
Power wire	Silicon wire
Brand	Maytech

Features:
•Strong, Reliable and Progressive Electric Brakes
•Start from a stop with Unsensored Motors as if it was Sensored
•Many Safety Features such as Current Control and Temperature Control Features
•Sensored and Unsensored (FOC) Field Oriented Control allows your electric skateboard to run with barely any motor noise.
•Built in 5V BEC
•Voltage: 8V to 60V (Up to 3S to 12S LiPo Voltage)
•Current: Up to 240A for a few seconds or 50A continous
•Regenerative Braking
•Sensored or Sensorless operation
•Great start-up torque with sensorless motors
