Tenda D301 Modem 300M Wireless ADSL2+ WiFi Router English Firmware USB 2.0 802.11n 6000V Lightning Protection IPTV | Компьютеры и офис

Характеристики







What It Does

Compliant with 802.11n standard, D301 combines the funtion of high speed ADSL2+modem, wireless router and 4-port switch in one device. Wireless speed is 6 times faster and WiFi range is much wider than 802.11g devices.D301 also supports the latest ADSL2+ standards to provide higher performance and longer reach from ISP's DSLAM. Connect it to the Internet service and provide up to 300Mbps wireless network for sharing high volume files, streaming music, videos, even online gaming among multiple computers. Additionally, with versatile USB port, you can easily share files and media from an external USB storage device with your friends or family.



Main Features

>>Combine the function of four-port modem, WiFi router and four-port switch in one device;
>>ransmission rate up to 300Mbps brings blazing fast Internet surfing;
>>Supports WPA/WPA2 wireless encryption mechanism to anti-rub network and protect privacy.





1-- All-in-One Device The D301 is a true one-stop solution, serving as a wired and wireless modem and router. It combines all the functionality of ADSL 2/2 modem, WiFi router, and 4-port switch, and adds to it with a range of Features, including USB sharing, IPTV, easy setup.

2-- Enhanced Wireless Performance Compliant with 802.11n, D301 delivers wireless speed up to 300Mbps which can bring blazing fast internet surfing like HD streaming, online games, and files sharing.   3-- Stable Continuous Network When the D301 router is placed in the living room, even if you are in the kitchen, you can also smoothly watch the video, transfer files.   4-- Powerful & Wider Coverage Featuring 2x5dBi external antenna, the D301 provides a boosted signal to ensure wireless coverage all around your home. Plus, with MIMO technology, it uses signal reflections to reduce dead spots, providing better wireless performance, transmission rates, stability and coverage.

5-- USB Sharing / Print The D301 provides a USB 2.0 port, which you can attach an external hard drive to your network, allowing you to share files throughout your home. 6-- 6KV Lightning Protection Lightning generating strong surge which can cause great damage to electronic devices like modem router. Designed with up to 6000 voltage lightning protection, the D301 can effectively avoid such damage. Thus it is ideal for use in areas where tough thunderstorms happen frequently.



• Standard & Protocol: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b; IEEE 802.3, IEEE 802.3u; ANSI T1.413, ITU G.992.1, ITU G.992.2, ITU G.992.3, ITU G.992.5
• Interface: 3 * 10 / 100Mbps auto-negotiation (Auto MDI / MDIX) LAN ports; 1 * 10 / 100Mbps auto-negotiation WAN / LAN Interchangeable port (Auto MDI / MDIX); 1 * RJ11 port; 1 * USB V2.0
• Antenna: 2 * external omni-directional antennas
• Button: 1 * Power; 1 * Reset / WPS
• Power: Input: 100-240V 50 / 60MHz; Output: 9V DC-1A
• Dimension: 171.61mm * 111.16mm * 34.47mm (L * W * H)
• LED: Power / SYS / Internet / DSL / WLAN / LAN / WPS / USB
• Transmission Media: Cat.5; Cat.5e; Cat.6; Phone Cable
• Frequency: 2.4GHZ
• Internet Connection Type: Dynamic IP; Static IP; PPPoE; IPoA
• USB V2.0: Yes
• Wireless Speed: 300Mbps
• TR-069: Yes
• Basic Features: Wireless Radio: On / Off; SSID Broadcast: On / Off; WDS: On / Off; Channel: Auto, 1-13; Channel Bandwidth: Auto, 20MHz, 40MHz
• Security: Wireless Access Control (Wireless MAC filter); Wireless Security; Enable / Disable; 64- / 128-bit WEP; WPA-PSK / WPA2-PSK
• Operating Mode: Wireless ADSL / ADSL2 + Modem Router, WDS
• DHCP Server: Yes
• Virtual Server: Yes
• Security: Port / URL / MAC Filter
• DDNS: Yes
• VPN Pass-through: PPPTP, L2TP, Ipsec
• Bandwidth Control: Yes
• VLAN: 802.1Q VLAN
• Default Settings: Login IP Address: 192.168.1.1; Internet Connection Types: Bridge, PPPoE, PPPoA, IPoA, DHCP (Dynamic IP); IP Address Pool: 192.168.1.2 - 192.168.1.254
• Temperature: Operating Temperature: 0 C ~ 40 C; Storage Temperature: -40 C ~ 70 C.
• Humidity: Operating Humility: 10% ~ 90% RH Non-condensing Storage; Humility: 5% ~ 90% RH Non-condensing
• Static Routing: Yes
• Logs: Yes
• Other: TR-069, IPV6, IPTV
• Package Content: D301; Power Adapter Quick Install Guide Ethernet Cable ADSL Splitter Phone Cable
• 3 Install Steps: Step 1. Connect all cables following the QIG; Step 2.Insert the CD into your PC's drive;
• Certification: 3C / ROHS / CE / FCC
•
