Характеристики
| Features |
| *24V DC permanent magnet motor |
| *Thrust up to 600 |
| *Elegant and compact design with small installation dimensions |
| *Built-in limit switches (not adjustable) |
| *Standard protection class: IP20 |
| *Noise level 48db: actuator not loade |
| *Duty cycle: Max10% or 2 minutes continuous use followed 18 minutes not in use |
| *Ambient temperature:-5°C to +40°C |
| Option |
| *Standard stroke:200-400 mm, can design as customer’s requirement |
| *Free load speed:7-50mm/s |
| *Rated load speed: 5-40mm/s |
| Spindle pitch | Max load | Typical Amp | Typical speed(mm/S) | Self lock Max (N) | ||||
| (mm) | (N) | |||||||
| push | pull | unloaded | full loaded | push | pull | |||
| OK618 | 4/1 | 5000 | 4500 | 3.5 | 18 | 16 | 4500 | 3500 |
| 1500N | ||||||||
| OK618 | 12/3 | 1000 | 1000 | 4.5 | 50 | 45 | 1000 | 800 |
| 1000N | ||||||||
