48V to 12V 10A Voltage Reducer Transformer Converter For GOLF CART Replacement Universal | Автомобили и мотоциклы

Характеристики

Specifications:

Input Voltage: 48V nominal

Input range: 40V to 60V

Input Current:10A (max)

No-load input current:≤10mA

Output Voltage:DC 12V ±2%

Output Current:10A

Ripple wave:50Mv

Starting delay time:≤ 2S

Maximum Efficiency:≥90%

Insulation resistance:≥20M Ω (between crust and earth, insulation resistance ≥20M Ω

FEATURES:

All epoxy sealed containers with Waterproof Die-Cast Aluminum Housing;

Light compact, convenient to use and transport;

Non-isolated

High efficiency:> 90%;

Operating temperature at -10 ℃ to +60 ℃; (max.+80 ℃)

With overload / over-current / over / low voltage protection, stable performance.

Auto recovery
