4WD Farm Tractor 45 Horsepower Multiple Equipment Can Be Selected | Автомобили и мотоциклы

Model

AOS454 (45HP)

Drive type

4*4

Engine:

Engine brand:

QUANCHAI/JIANGDONG/YANGDONG

Model:

4B2-45M22/YD4JT/JDM490T5

Type:

4 cylinder,water-cooling, In-line, direct injection

Capacity of fuel tank:

41L

Bore*Stroke:

90*100/95*105

Rated speed:

2350rpm

Engine power:

45hp/28.2kw

Displacement:

2.544/2.977/2.545L

Transmission:

Clutch:

Dry,single clutch

PTO size:

6 teethφ35

PTO Speed:

540/720rpm

Gear shift:

(4+1)*2

Hydraulic system:

Hydraulic output valve:

2-Way opitonal

Three point linkage:

Category of 3-point link:

Category I

Lifting capacity(at point of 610mm):

>5.8KN

Technical parameter:

Dimension(L*W*H):

3500*1600*1900mm

Min.operation weight:

1520kg

Wheel base

1800mm

Track base- front wheel

1000/1250mm

Track base-rear wheel

1000-1300mm

The Min. Clearance:

310mm

Model

AOS404

Drive mode

4WD

Length(without ballast and linkage)

3150mm

Width

1550mm

Height (to exhaust)

1980mm

Height (to Cabin Top)

2250mm

Tread

Front Wheel

1200mm (optional 1000, 1300)

Rear Wheel

1200mm (optional 1000, 1300)

Wheel base

1450mm

Min. Ground Clearance

277mm

Min. Radius of

Turning

One-side braking

2.4m

No braking

2.8m

Net Weight

1300kg

Model

LD4L23

Type

Vertical, Water Cooled and
4-stroke

Rated Power

29.4KW

Fuel

Diesel

Fuel consumption

≤245g/kW.h

Rated Rev.

2400rpm

Tire

Front tire

6.00-16

Rear tire

9.5-24(optional
8.3-24,11.2-24)

Connection between engine and clutch

Shaft connection

Clutch

Single Disc, Dry-Friction,
Single Stage

Transmission Box

(4+1)*2 Mechanical Type

Steering

Mechanical or Hydraulic Type

Suspension Type

Post positioned Tri-point Suspension, Catalogue I

Type and Rev.(r/min)

Single speed non-independent type 720 or double speed
Non-independent 540/1000.

Spline Size(mm)

Post positioned I35 Rectangle Spline with 6 teeth(6*28.91*34.79*8.69).
